Anti-Terror large luggage Security X Ray Baggage Screening Equipment for Airport
Applications:
Airports,
Transport terminals,
Buildings,
Factories (to find needle in clothing, shoes, bags),
Courthouses,
Embassies,
Military installations,
Prisons,
Hotels,
Schools ,
Convention centers,
Security checkpoints,
Special events location
Competitive Advantage:
Integrated, cost Effective, Turn-Key Security
Fit for small Baggage and Parcel Security Inspection.
Increased detection capability
Friendly interface for ease-of-use
Reliable performance and uncompromising value
Specifications:
| Tunnel Size: | 1000(W)*1000(H)mm |
| Conveyor Speed: | 0.22m/s |
| Conveyor Max Load: | 200kgs |
| Dose per Inspection: | <1.7 μGy/h |
| Resolution: | <0.101mm Metal Wire |
| Penetration: | 34mm Steel |
| Film Safety: | Guarantee ISO1600 Film |
| X-ray Leakage: | <0.1 μGy/h (at a distance of 5cm From external housing) |
| Generate direct: | Downward |
| Generate angle: | 80 degree |
| Anode Voltage: | 100-160Kv |
| Anode power: | 0.4 to 1.2mA |
| Cooling / Duty Cycle: | Oil Cooling /100% |
| X-ray Sensor: | L-Shaped Photodiode Array (mono-energetic), 12bit Deep |
| Monitor: | High Resolution Color, LCD Accord, 17 inch |
| Image Processing: | Edge enhancement, image strengthening, image lightening, reducing darkening, image returning, image retrieval. |
| Image Grey Level: | 4096 |
| Image Max Resolution: | 1024 * 1280 pixel |
| Image Processing: | 24bit for processing real time |
| Image storage: | Storage 60000 pictures in real time |
| Zones & Zoom: | 1-9 Image regions, 2, 4, 8, 16 Times Enlarge, Whole screen continuous observation |
| Operation temperature/Humidity: | 0℃-45℃/20%-95%(non-condensing) |
| Storage Temperature/Humidity: | -20℃-60℃/20%-95%(non-condensing) |
| Operation Power: | 220VAC(±10%)50±3Hz |
| Power Consumption: | 1.8 KW (max), 0.3KW(working) |
| Noise: | <60db |
Fit for small Baggage and Parcel Security Inspection.
Increased detection capability
Friendly interface for ease-of-use
Reliable performance and uncompromising value
